Products
BC Power Systems designs and manufactures custom power solutions for the most demanding military and aerospace applications. Our product line spans two core categories: military power supplies ranging from 10 watts to 30 kilowatts for ground, airborne, and shipboard platforms, and airborne power control products including power monitors, relay units, and voltage regulators. Built with the latest solid-state technology and engineered to meet rigorous mission requirements, every unit is tailored to your specifications. Browse our previous designs below, or contact us to discuss your custom needs.
Military Power Supplies
product details
BC-108
AC to DC, 5 Output, 150 Watt
DESCRIPTION
BC Systems Inc., is a designer and manufacturer of military power supplies, using the latest solid state device technology to achieve reliable specification compliant products. Power supplies are designed to meet or exceed customer specified environmental requirements. Military applications include all service platforms: ground, air and shipboard. Power supply technical qualifications are based on our vast experience in the design and manufacture of power supplies.
BC Systems Inc employs innovative packaging and thermal management techniques which are manufactured onsite providing enhanced production process control. Our complete in-house manufacturing capability provides our design and manufacturing team with the advantage of supplying products that achieve maximum performance, in the smallest package possible, within schedule requirements.
Specifications
115 VRMS, 3 Phase, 400 Hz
IAW MIL-STD-704
Power Factor: ≥ 0.86
Inrush current ‹ 10 A Max.
+12 VDC @ 4.3 Amperes Max.
-12 VDC @ 1.2 Amperes Max.
+5 VDC @ 4.5 Amperes Max.
-5 VDC @ 2.0 Amperes Max.
Ripple & Noise < 25mVp-p
+28 VDC switched pass-thru
75% Minimum
1.44 Lbs. Max.
Over-voltage
Over-current
Over-temperature
Cooling Induction
Operating: -55°C to +85°C
Non-Operating: -65°C to +95°C
10.1" × 5.2" × 0.70"
Qualifications
Shock IAW MIL-STD-810D
EMI/EMC IAW MIL-STD-461E
Application
Airborne Counter Measures
